LED indicators:
- Y
Product colour:
- Black
Rack mounting:
- N
Input current:
- 1 A
Power source:
- DC
Input voltage:
- 12 V
Power consumption (max):
- 12.11 W
Power supply included:
- Y
Storage relative humidity (H-H):
- 5 - 90%
Operating relative humidity (H-H):
- 10 - 90%
Operating temperature (T-T):
- 0 - 40 °C
Storage temperature (T-T):
- -40 - 70 °C
Heat dissipation:
- 41.32 BTU/h
Switch type:
- Unmanaged
Width:
- 209 mm
Height:
- 26 mm
Depth:
- 126 mm
Networking standards:
- IEEE 802.3p
- IEEE 802.3x
- IEEE 802.3
- IEEE 802.3ab
- IEEE 802.3z
- IEEE 802.3u
Ethernet LAN data rates:
- 10,100,1000 Mbit/s
Auto MDI/MDI-X:
- Y
Auto-negotiation:
- Y
10G support:
- N
Cables included:
- LAN (RJ-45)
Quick start guide:
- Y
Basic switching RJ-45 Ethernet ports quantity:
- 5
Basic switching RJ-45 Ethernet ports type:
- 2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity:
- 5
Harmonized System (HS) code:
- 85176990
MAC address table:
- 16000 entries
Packet buffer memory:
- 1.5 MB
Switching capacity:
- 25 Gbit/s
Jumbo frames support:
- Y
Store-and-forward:
- Y
Forwarding rate:
- 18.6 Mpps
Jumbo frames:
- 10000
Power over Ethernet (PoE):
- N
